Brand

Schneider

Model Name

Zelio

Product Code | Control Circuit Voltage

RXM4AB1JD | 12 V DC

RXM4AB1B7 | 24 V AC

RXM4AB1BD | 24 V DC

RXM4AB1E7 | 48 V AC

RXM4AB1ED | 48 V DC

RXM4AB1FD | 110 V DC

RXM4AB1F7 | 120 V AC

RXM4AB1MD | 220 V DC

RXM4AB1P7 | 230 V AC

RXM4AB1U7 | 240 V AC

Product Type

Plug In Relays

Series Name

Miniature

Device Short Name

RXM

Description

4 Change Over - 6 AMPS Contact Rating

Current Rating

6 A

Contacts Type And Composition

4 C/O

Utilisation Coefficient

20 %

Status LED

Without

Control Type

Lockable Test Button

Shape Of Pin

Flat

Mechanical Durability

10000000 cycles

Maximum Switching Voltage

250 V Conforming To IEC

Operating Position

Any Position

Dimension

79 mm x 78.45 mm

Warranty

As Per Manufacturer Terms and Condition
